STEP BY STEP FOR OPERATION

1)     Prepare electrolyte:

Pour 2500cc distilled water (or pure water) into a container made of glass, china or heat-resistant plastic (warning: aluminium container is prohibitted). Put 1 bottle of electrolyte powder into the water slowly, stir until it is dissolved completely. It generates heat while dissolving, and need to be cooled for about 20 minutes.

2)     Add electrolyte:

Screw off the top cover, add electrolyte into the generator carefully until the water level close to the “high” line, then screw on the cover. The best water level is between “middle” and “high” lines.

3)     Prepare the gas filter:

 Screw off the gas filter, add 100cc pure water or ethanol, then screw it on. Ethanol(alcohol) of 70% above is for fire-polishing acryl (organic glass), because the mixture of hydrogen and ethanol volatile can lower the flame temperature. The remaining ethanol should be poured out of the gas filter everyday after use.

4)     Switch on and check:

Switch on the power, the indicator light turns bright, the fan begins running and the ammeter indicates around 55A(300-350W), 120A(600W) or 160A(1000W); gas can be felt out of the outlet (within 1 minute), the barometer indicates 0.01-0.05mpa. If you seal it with a finger, the gas pressure will go up until over 0.1mpa and the ammeter indicates zero; move out the finger, the gas pressure will go down and the ammeter indicates well.

5)     Link the rubber pipe and torch and ignite:

Link the rubber pipe and torch to the gas outlet. Hold the torch and open the valve on the torch, then ignite and observe the color of flame. The normal color is light blue. The valve can be adjusted to control the flame. To change a torch, you should turn off the valve to extinguish first.

For fire-polishing acryl, choose a suitable torch, let the flame 45 degree to the coarse surface of acryl and move it parallel. Anyone can use it adroitly after several hours of practice.

6)     Add water timely:

After several hours of operation, the water level may fall below the “middle” line, and the “fuel”—water should be added. Distilled water is the best choice, then is purified water, cold boiled water, tap water and mineral water, orderly.

How to add water:

1.      Turn off the torch

2.      Switch off the power and open the valve on the torch to let out the remaining gas

3.      Screw off the top cover

4.      Add water close to the “high” line

5.      Screw on the cover and switch on, and it can work again
